Z SPECIAL-CARRERA : ENGINE : CYLINDER HEADS and COMPONENTS
| Part Number | Description | Price | Add | |
|---|---|---|---|---|
ZHL14.0  |
Intake Guide | $0 |
|
|
|
ZHL15.0 |
Exhaust Guide 11mm | $0 |
|
|
|
ZHL15.1 |
Exhaust Guide 9mm | $0 |
|
|
ZHL25.0  |
Intake valve cover, for type 547 / 692 547 04 225 1 |
3812bd | $150 |
|
|
ZHL25.1 |
intake valve cover, for type 587692 104 401 00 | 3812j | $175 |
|
|
ZHL26.0 |
exhaust valve cover, for type 547 / 692 547 04 226 | 3812f | $125 |
|
|
ZHL26.1 |
exhaust valve cover, for type 587/1 692 104 405 00 | 3812h | $0 |
|
|
ZHL26.2 |
exhaust valve cover, for type 587/3 547 104 405 00 | 3812i | $150 |
|
|
ZHL28.0 |
Locking plate for cap nut, copper, 547 04 235 8 required | 3812l | $1.5 |
|
|
ZHL29.0 |
Cap nut for valve cover 900 070 003 02 | 3812k | $5 |
|
|
ZHL30.1 |
intake valve, 48 mm for type 692/3, 3A and 587/1 HEREHEREHERE |
719 105 401 00 | $90 |
|
|
ZHL30.2 |
intake valve, 50 mm | 587 105 401 01 | $90 |
|
|
ZHL31.1 |
Exhaust valve, 41 mm for type 692/3, 3A and 587/1 9mm Stem HEREHEREHERE |
719 105 405 50 | $105 |
|
|
ZHL31.2 |
Exhaust valve, 43 mm 9mm Stem | 587 105 405 00 | $105 |
|
|
ZHL39.2 |
Closing piece long for 587 | $15 |
|
|
|
ZHL40.0 |
HALF MOON SEALING PIECE 547.04.228 FITS 4-CAM |
3812g | $5 |
|
|
ZHL41.0 |
Rubber plug for cylinder head, 547 04 223 16 required |
3812m | $4 |
|
|
ZHL42.0 |
Lower intake Valve Cover Seal 547/692 |
VC!! | $20 |
|
|
ZHL43.0 |
Upper intake Valve Cover Seal 547/692 |
VCI | $20 |
|
|
ZHL44.0 |
Exhaust Valve Cover Seal new version 547-04-229 Fits 547/692 |
547-04-229 | $20 |
|
|
ZHL44.1 |
Exhaust Valve Cover Seal new version 692-104-901-00 Fits 587 |
692-104-913-00 | $20 |
|
|
ZHL70.0 |
Valve cover seal set 547+692 | $200 |
|
|
|
ZHL70.1 |
Valve cover seal kit 587 | $200 |
|
Prices and availability subject to change without notice.
