ENGINE - Piston & Cylinder Sets
| Part Number | Description | Price | Add | |
|---|---|---|---|---|
EPC1.0 |
AA PISTON & CYLINDER SET , with 80.0mm Bore CAST IRON CYLINDER , PISTON with 22mm Wrist Pin 008 11 80S Fits Early 1500 |
008 11 80S | $684.00 |  |
| EPC1.1 |
AA PISTON & CYLINDER SET , with 80.0mm Bore BIRAL CYLINDER , JE Forged PISTON with 22 mm Wrist Pin 008 11 80S JE Fits Early 1500 |
008 11 80S JE | $1175.00 | |
| EPC1.2 |
PISTON & CYLINDER SET , with 82.5mm Bore CAST IRON CYLINDER , MAHLE OE PISTON NOT FOR Counterweighted Crankshaft Call for price & availability 616-103-906-01MA Fits 356C |
616-103-906-01MA | $1.00 | |
| EPC1.3 |
PISTON & CYLINDER SET , with 82.5mm Bore NICKASIL CYLINDER , for 356 SC & 912 MAHLE OE CAST PISTON Call for price & availability 616-103-904-06MA Fits 356SC 912 |
616-103-904-06MA | $1.00 | |
| EPC1.4 |
AA PISTON & CYLINDER SET , with 82.5mm BIRAL CYLINDER , JE FORGED Piston SPECIAL 11.5:1 COMPRESSION RATIO 008 11 82P JE Fits 356C SC 912 |
008 11 82P JE | $1258.40 | |
| EPC1.5 |
AA PISTON & CYLINDER SET , with 83.5mm BIRAL CYLINDER , JE FORGED Piston SPECIAL 9.5:1 COMPRESSION RATIO 008 11 83C JE Fits 356C SC 912 |
008 11 83C JE | $1215.20 | |
| EPC1.6 |
AA PISTON & CYLINDER SET , with 83.5mm BIRAL CYLINDER , JE FORGED PISTON SPECIAL 11.5:1 COMPRESSION RATIO 008 11 83P JE Fits 356C SC 912 |
008 11 83P JE | $1215.20 | |
| EPC1.7 |
AA PISTON & CYLINDER SET , with 86.0mm BIG BORE CAST IRON CYLINDER JE FORGED PISTON SPECIAL 9.2:1 COMPRESSION RATIO 008 11 86PA Fits 356A/B with 22 degree heads |
008 11 86PA | $524.80 | |
| EPC1.8 |
AA PISTON & CYLINDER SET , with 86.0mm BIG BORE CAST IRON CYLINDER PERFORMANCE PISTON SPECIAL 9.2:1 COMPRESSION RATIO 008 11 86PA Fits 356C 912 |
008 11 86PA | $532.00 | |
| EPC1.9 |
AA PISTON & CYLINDER SET , with 86.0mm BIG BORE CAST IRON CYLINDER PERFORMANCE PISTON SPECIAL 9.2:1 COMPRESSION RATIO 008 11 86PS Fits 356C SC 912 |
008 11 86PS | $532.00 | |
| EPC1.10 |
AA PISTON & CYLINDER SET , with 86.0mm BIG BORE CAST IRON CYLINDER JE FORGED PISTON SPECIAL 9.5:1 COMPRESSION RATIO 008 11 86C JE Fits 356C SC 912 |
008 11 86C JE | $1105.00 | |
| EPC1.11 |
AA PISTON & CYLINDER SET , with 86.0mm BIG BORE BIRAL CYLINDER PERFORMANCE PISTON SPECIAL 9.2:1 COMPRESSION RATIO 008 11 86PB Fits 356C SC 912 |
008 11 86PB | $809.60 | |
| EPC1.13 |
AA PISTON & CYLINDER SET , with 86.0mm BIG BORE BIRAL CYLINDER JE FORGED PISTON SPECIAL 9.5:1 COMPRESSION RATIO 008 11 86P JE Fits 356C SC 912 |
008 11 86P JE | $1215.20 | |
| EPC1.14 |
AA PISTON & CYLINDER SET , with 86.0mm BIG BORE BIRAL CYLINDER CP FORGED PISTON SPECIAL 9.5:1 COMPRESSION RATIO 008 11 86P CP Fits 356C SC 912 |
008 11 86P CP | $1727.20 | |
EPC1.15 |
LN PISTON & CYLINDER SET , with 86.0mm BIG BORE NICKASIL CYLINDER MAHLE MOTORSPORTS FORGED PISTON , SPECIAL 9.5:1 COMPRESSION RATIO PS86-004N Fits 356SC 912 |
PS86-004N | $4160.00 | |
| EPC1.16 |
LN PISTON & CYLINDER SET , with 86.0mm BIG BORE NICKASIL CYLINDER MAHLE MOTORSPORTS FORGED PISTON , SPECIAL 9.5:1 COMPRESSION RATIO PS86-003N Fits 356SC 912 |
PS86-003N | $4160.00 | |
| EPC1.17 |
LN PISTON & CYLINDER SET , with 86.0mm BIG BORE NICKASIL CYLINDER MAHLE MOTORSPORTS FORGED PISTON , SPECIAL 9.5:1 COMPRESSION RATIO PS86-005N Fits 356SC 912 |
PS86-005N | $4160.00 | |
| EPC1.18 |
LN PISTON & CYLINDER SET , with 91.0mm BIG BORE NICKASIL CYLINDER MAHLE MOTORSPORTS FORGED PISTON , SPECIAL 9.5:1 COMPRESSION RATIO PS91-001N Fits 356SC 912 |
P91-001N | $4160.00 | |
| EPC1.19 |
LN PISTON & CYLINDER SET , with 91.0mm BIG BORE NICKASIL CYLINDER MAHLE MOTORSPORTS FORGED PISTON , SPECIAL 9.5:1 COMPRESSION RATIO PS91-002N Fits 356SC 912 |
P91-002N | $4160.00 | |
| EPC1.20 |
LN PISTON & CYLINDER SET , with 91.0mm BIG BORE NICKASIL CYLINDER MAHLE MOTORSPORTS FORGED PISTON , SPECIAL 9.5:1 COMPRESSION RATIO PS91-003N Fits 356SC 912 |
P91-003N | $4160.00 | |
| EPC2.0 |
GASKET COPPER RING , 82.5mm CYLINDER BORE , 0.25mm THICK , CYLINDER to ENGINE CRANKCASE 539-04-209 |
539-04-209 | $3.60 | |
| EPC2.1 |
GASKET COPPER RING , 82.5mm CYLINDER BORE , 0.50mm THICK , CYLINDER to ENGINE CRANKCASE XXX-XXX-XXX-XX |
XXX-XXX-XXX-XX | $5.75 | |
| EPC2.2 |
GASKET COPPER RING , 82.5mm CYLINDER BORE , 1.00mm THICK , CYLINDER to ENGINE CRANKCASE 616-104-191-00 |
616-104-191-00 | $4.50 | |
| EPC4.1 |
CIRCLIP , PISTON PIN RETENTION , FULL ENGINE SET , SECURES the PISTON PINS inside the PISTONS 900-178-002-00 Retaining ring style for standard piston pin. |
900-178-002-00 or 99142A420 | $9.95 | |
| EPC5.0 |
PISTON RING SET , 80.0mm CYLINDER BORE , for 3 RING PISTON , FULL ENGINE SET 3.0mm / 3.0mm / 5.0mm , DEVES Brand ( SWEDEN QUALITY Manufacture ) 1357 |
1357 | $119.00 | |
| EPC5.2 |
PISTON RING SET , 82.5mm CYLINDER BORE , for 3 RING PISTON , FULL ENGINE SET 3.0mm / 3.0mm / 5.0mm , DEVES Brand ( SWEDEN QUALITY Manufacture ) 1358 |
1358 | $119.00 | |
| EPC5.3 |
PISTON RING SET , 82.5mm CYLINDER BORE , for 4 RING PISTON , FULL ENGINE SET 2.0mm / 2.0mm / 2.0mm / 5.0mm , DEVES Brand ( SWEDEN QUALITY Manufacture ) 1359 |
1359 | $119.00 | |
| EPC5.4 |
PISTON RING SET , 82.5mm CYLINDER BORE , for 3 RING PISTON , FULL ENGINE SET 1.50mm / 2.0mm / 4.0mm , DEVES Brand ( SWEDEN QUALITY Manufacture ) 1858 S-90 SC 912 |
1858 | $119.00 | |
| EPC5.5 |
PISTON RING SET , 80.0mm CYLINDER BORE , for 3 RING PISTON , FULL ENGINE SET 3.0mm / 3.0mm / 5.0mm , GRANT Brand ( U.S.A. QUALITY Manufacture ) P1060 |
P1060 | $64.95 | |
| EPC5.6 |
PISTON RING SET , 80.0mm CYLINDER BORE , for 3 RING PISTON , FULL ENGINE SET 3.0mm / 3.0mm / 5.0mm , HASTINGS Brand ( U.S.A. QUALITY Manufacture ) H8011C |
H8011C | $120.96 | |
| EPC5.7 |
PISTON RING SET , 82.5mm CYLINDER BORE , for 3 RING PISTON , FULL ENGINE SET 1.5mm / 1.5mm / 3.0mm , HASTINGS Brand ( U.S.A. QUALITY Manufacture ) H8211F |
H8211F | $87.95 | |
| EPC5.8 |
PISTON RING SET 83.5mm 3 Ring 1.5mm / 1.5mm / 3.0mm C1790-20 |
C1790-20 | $90.95 | |
| EPC5.9 |
PISTON RING SET , 82.5mm CYLINDER BORE , for 4 RING PISTON , FULL ENGINE SET 2.0mm / 2.0mm / 2.0mm / 5.0mm , GRANT Brand ( U.S.A. QUALITY Manufacture ) P1129.000 |
P1129.000 | $63.95 | |
| EPC5.10 |
PISTON RING SET , 86.0mm CYLINDER BORE , for 3 RING PISTON , FULL ENGINE SET 1.5mm / 1.5mm / 3.0mm , HASTINGS Brand ( U.S.A. QUALITY Manufacture ) H8611F |
H8611F | $79.95 | |
| EPC6.0 |
AA PISTON SET , 80.0mm OUTSIDE DIAMETER , FULL ENGINE SET 3 RING PISTONS , 3.0mm / 3.0mm / 5.0mm RING GROOVES , with 22mm Wrist Pins 008 11 80P Fits Early 1500 |
008 11 80P | $241.60 | |
| EPC6.1 |
AA PISTON SET , 82.5mm OUTSIDE DIAMETER , FULL ENGINE SET JE FORGED PISTONS , SPECIAL 11:1 COMPRESSION RATIO , 3 RING PISTONS 3.0mm / 3.0mm / 5.0mm RING GROOVES , with 22mm Wrist Pins 008 11 80JEP Fits 356SC 912 |
008 11 80JEP | $666.40 | |
| EPC6.2 |
AA PISTON SET , 83.5mm OUTSIDE DIAMETER , FULL ENGINE SET JE FORGED PISTONS , SPECIAL 11.5:1 COMPRESSION RATIO , 3 RING PISTONS 3.0mm / 3.0mm / 5.0mm RING GROOVES , with 22mm Wrist Pins 008 11 83JEP Fits 356SC 912 |
008 11 83JEP | $660.80 | |
| EPC6.3 |
AA PISTON SET , 86.0mm OUTSIDE DIAMETER , FULL ENGINE SET PERFORMANCE PISTONS , SPECIAL 22 Degree CHAMBER Cylinder Head , 3 RING PISTON 1.5mm / 1.5mm / 3.0mm RING GROOVES 008 11 86EP Fits 356AB with 22 degree heads |
008 11 86EP | $319.20 | |
| EPC6.4 |
AA PISTON SET , 86.0mm OUTSIDE DIAMETER , FULL ENGINE SET PERFORMANCE PISTONS , 3 RING PISTON 1.5mm / 1.5mm / 3.0mm RING GROOVES 008 11 86SP Fits 356SC 912 |
008 11 86SP | $295.20 | |
| EPC6.5 |
AA PISTON SET , 86.0mm OUTSIDE DIAMETER , FULL ENGINE SET JE FORGED PISTONS , 3 RING PISTON , 9.5:1 COMPRESSION RATIO 1.5mm / 1.5mm / 3.0mm RING GROOVES 008 11 86JEAP Fits 356SC 912 |
008 11 82JEAP | $660.80 | |
| EPC6.6 |
AA PISTON SET , 86.0mm OUTSIDE DIAMETER , FULL ENGINE SET JE FORGED PISTONS , 3 RING PISTON , 9.5:1 COMPRESSION RATIO 1.5mm / 1.5mm / 3.0mm RING GROOVES 008 11 86JEAP Fits 356SC 912 |
008 11 8JEP | $660.80 | |
| EPC6.7 |
WOSSNER PISTON SET , 82.5mm OUTSIDE DIAMETER , FULL ENGINE SET SPECIAL PREMIUM FORGED COATED PISTONS , SPECIAL 9.6:1 COMPRESSION RATIO with 22mm Wrist Pins K901D Fits 356SC 912 |
K901D | $652.80 | |
| EPC6.8 |
WOSSNER PISTON SET , 83.0mm OUTSIDE DIAMETER , FULL ENGINE SET SPECIAL PREMIUM FORGED COATED PISTONS , SPECIAL 9.6:1 COMPRESSION RATIO with 22mm Wrist Pins K901D050 Fits 356SC 912 |
K901D050 | $652.80 | |
| EPC6.9 |
WOSSNER PISTON SET , 83.5mm OUTSIDE DIAMETER , FULL ENGINE SET SPECIAL PREMIUM FORGED COATED PISTONS , SPECIAL 9.6:1 COMPRESSION RATIO with 22mm Wrist Pins K901D100 Fits 356SC 912 |
K901D100 | $652.80 | |
| EPC7.0 |
AA CYLINDER SET , 80.0mm BORE DIAMETR , CAST IRON CYLINDER , FULL ENGINE SET 008 11 80L Fits Early 1500 |
008 11 80L | $410.40 | |
| EPC7.1 |
AA CYLINDER SET , 82.5mm INSIDE BORE DIAMETR , BIRAL CYLINDERS , FULL ENGINE SET 008 11 82SL |
008 11 82SL | $353.60 | |
| EPC7.2 |
AA CYLINDER SET , 83.0mm INSIDE BORE DIAMETR , BIRAL CYLINDERS , FULL ENGINE SET 008 11 82BL |
008 11 82BL | $428.00 | |
| EPC7.3 |
AA CYLINDER SET , 83.5mm INSIDE BORE DIAMETR , BIRAL CYLINDERS , FULL ENGINE SET 008 11 83BL |
008 11 83BL | $405.60 | |
| EPC7.4 |
AA CYLINDER SET , 86.0mm INSIDE BORE DIAMETR , CAST IRON CYLINDERS , FULL ENGINE SET 008 11 86SL |
008 11 86SL | $299.20 | |
| EPC7.5 |
AA CYLINDER SET , 86.0mm INSIDE BORE DIAMETR , BIRAL CYLINDERS , FULL ENGINE SET 008 11 86BL |
008 11 86BL | $517.60 | |
| EPC7.6 |
DURABAR CYLINDER SET 80-86mm BORE , State size DURABAR XX.X |
DURABAR XX.X | $750.00 | |
| EPC7.7 |
DURABAR CYLINDER SET 90-91 BORE , State size DURABAR XX.X |
DURABAR XX.X | $950.00 | |
Prices and availability subject to change without notice.
